Events

Specifics:
--------------------------------------------------------------------------------
In the case of Xen, a ring buffer is provided to hold VM events for consumption
by an external service which accesses this buffer from an observation VM.

Within its Xen driver, LibVMI enables event delivery when the initialization
mode has the VMI_INIT_EVENTS mode set:

    vmi_init_complete(&vmi, vm_name, VMI_INIT_DOMAINNAME | VMI_INIT_EVENTS,
                      NULL, VMI_CONFIG_GLOBAL_FILE_ENTRY, NULL, NULL))

Using LibVMI events is possible in four general steps:
    1) The allocation of an event structure to configure delivery of
        events (frequency, synchronous vs asynchronous, access mode, callback).
        Specific options for configuration are event-specific.
    2) The registration of this event with LibVMI via vmi_register_event().
        Upon receipt of an event matching one configured via vmi_event_t,
        it is passed to the configured callback.
    3) Invocation of the LibVMI function vmi_events_listen() which checks for
        incoming events and, if found, passes each to the appropriate callback.
        The event passed to its registered callback is augmented with
        information aiding in its interpretation (e.g., the page upon which
        a write operation was invoked, the VCPU used to execute an
        instruction, and/or the relevant instruction pointer.
    4) When use of the events subsystem has completed, unregistration of
        an individual event must be performed via vmi_clear_event or
        implicitly via vmi_destroy at program exit.

An example vmi_event_t allocation and subsequent configuration is shown below.
For full demonstrations, please consult the examples/ directory within the
LibVMI source tree.

    vmi_event_t *cr3_write_event = calloc(1, sizeof(vmi_event_t));
    cr3_write_event->version = VMI_EVENTS_VERSION;
    cr3_write_event->type = VMI_EVENT_REGISTER;
    cr3_write_event->reg_event.reg = CR3;
    cr3_write_event->reg_event.in_access = VMI_REGACCESS_W;
    cr3_write_event->callback = cr3_change_cb;

  Where cr3_change_cb is a pointer to a function with the prototype:
    void callback_name(vmi_instance_t vmi, vmi_event_t *event)
  All event callbacks must use this prototype; its return is not inspected
    by the vmi_events_listen() after invocation.

After creation, an event must be registered:

    vmi_register_event(vmi, cr3_write_event);

Next, the library user must await event delivery (exiting if interrupted
by a signal or other error/exit condition):

    while(!interrupted){
        vmi_events_listen(vmi, 1000);
    }

Finally, the library user MUST call vmi_destroy(vmi) upon exit. While this
action will cleanly unregister for all events, it is also recommended that
the library user call vmi_clear_event for each event structure when event
listening has concluded. This operation will unregister for the given event
type and remove the pointer to the event from tracking structures within
LibVMI.  For some event types, vmi_event_clear may be required within the
callback to ensure VM execution continues (though the same event structure
can be re-used and re-registered as needed).

NOTE:
   All memory management of vmi_event_t structures is the responsibility
   of the library user - LibVMI only tracks pointers to these structures.

                                    ---

#define VMI_EVENT_INVALID           0
#define VMI_EVENT_MEMORY            1   /**< Read/write/execute on a region of memory */
#define VMI_EVENT_REGISTER          2   /**< Read/write of a specific register */
#define VMI_EVENT_SINGLESTEP        3   /**< Instructions being executed on a set of VCPUs */
#define VMI_EVENT_INTERRUPT         4   /**< Interrupts being delivered */
#define VMI_EVENT_GUEST_REQUEST     5   /**< Guest-requested event */
#define VMI_EVENT_CPUID             6   /**< CPUID event */
#define VMI_EVENT_DEBUG_EXCEPTION   7   /**< Debug exception event */
#define VMI_EVENT_PRIVILEGED_CALL   8   /**< Privileged call (ie. SMC on ARM) */
#define VMI_EVENT_DESCRIPTOR_ACCESS 9   /**< A descriptor table register was accessed */
#define VMI_EVENT_FAILED_EMULATION  10  /**< Emulation failed when requested by VMI_EVENT_RESPONSE_EMULATE */
#define VMI_EVENT_DOMAIN_WATCH      11  /**< Watch create/destroy events */
#define VMI_EVENT_VMEXIT            12  /**< VMEXIT */
